Home > Storage Systems > Pallet Racking
Pallet Racking
Iron Fist Pallet Rack
A safe, strong and resistant system, easy to assemble and to adapt to all different warehouses needs. IRON FIST is the industrial rack for heavy storage that optimizes the spaces and multiply the storage capacity.
All your pallet storage needs are covered
The Iron Fist system from ROSSS is as strong as it is versatile. With the Iron Fist system you can design any modern system of pallet racking to suit your individual requirements.
SPIMA can design and offer you the most suitable system to compliment your logistic processes based on our extensive experience. Contact us for a consultation. Information needed:
- Layout of the area
- Clear height
- Type of material handling equipment to be used (forklift/reach truck etc.)
- Pallet type (euro/industrial/other)
- Pallet height
- Pallet weight
- Pallet overhang
Technical Data
UPRIGHT
The steel used for making the uprights is of a certified structural type S350 GD, with a minimum unit yield strength of 350 N/mm2.
The product is obtained by galvanized coils through pressing and cold roll forming process.
BEAMS
The steel used for making the beams is of a certified structural type S355 MC, with a minimum unit yield strength of 355 N/mm2.
The product is obtained by coils through profiling and then seaming.
FOOT PLATES
The steel used for making the foot plates is of a certified structural type S250 GD, with a minimum unit yield strength of 250 N/mm2.
The product is obtained by pickled coils with a pressing process and then galvanizing.
DIAGONALS AND HORIZONTALS
The steel used for making diagonals and horizontals is of a certified structural type S250 GD, with a minimum unit yield strength
of 250 N/mm2. The product is obtained by galvanized coils through profiling.
CONNECTORS FOR WELDED BEAMS
The steel used for making the connectors is of a certified structural type S355 MC, with a minimum unit yield strength of 355 N/mm2.
The product is obtained by coils through a pressing process.
DRIVE-IN RAIL PALLET SUPPORT
The steel used for making the rail is of a certified structural type S350 GD, with a minimum unit yield strength of 350 N/mm2.
The product is obtained by coils through a pressing process.
DRIVE-IN UPPER CONNECTION
The steel used for making the cross bracings is of a certified structural type S250 GD, with a minimum unit yield strength
of 250 N/mm2. The product is obtained by bars through a pressing process.
DRIVE-IN CROSS BRACING
The steel used for making the cross bracings is of a certified structural type S250 GD, with a minimum unit yield strength
of 250 N/mm2. The product is obtained by bars through a pressing process
